DESCRIPTION

ThermalGuard CC1.7 is a fast set, hybrid cell, water-blown spray polyurethane foam (SPF) insulation that achieves exceptional yield without off-gassing in the drum. ThermalGuard CC1.7 is applied as a liquid and expands 25x in seconds to fill and seal building cavities of any shape and size. It exhibits superior thermal insulation, air-barrier, and sound attenuation properties compared to conventional insulation materials. Once fully cured ThermalGuard CC1.7 remains rigid maintaining significant structural strength and thermal insulation properties in adverse conditions across a wide variety of applications.

ThermalGuard CC1.7 is designed for use in residential and commercial structures, exterior foundation or perimeter insulation, below grade applications, exterior tank/pipe insulation, etc. ThermalGuard CC1.7 can replace a 2.0 lb density foam in applications where a lower cost, semi-rigid foam with superior sprayability, appearance, compressive strength and smooth skin is desired.

KEY BENEFITS

  • Adheres to Virtually Any Surface
  • Adds Structural Support
  • Seals & Insulates in One Step
  • Great for Insulating Hard-to-Reach Areas
  • Applied Using Water as the Blowing Agent
  • Saves up to 50% on Heating & Cooling Costs

1.7

Density

5.2

R-value

0
Tensile Strength (PSI)
15-0
Compressive Strength (PSI)

Hybrid Formulation

This high yield, water-blown, SPF insulation is similar to a standard 245fa blown 2.0 lb density product, but offers higher yield and no off-gassing in the drum. ThermalGuard OC1.6 can replace a 2.0 lb density foam in applications where a lower cost, semi-rigid foam with superior sprayability, appearance, compressive strength and smooth skin is desired.

Open-Cell Content

10 – 20%
